Prime Zen ZEN-RGBW

Prime Zen ZEN-RGBW — ZEN-RGBW 4-Channel LED Strip Controller by Bright Ideas Lighting Ahmedabad RGBW Strip Controller Prime Zen

Light Controller · RGBW Strip Controller

Model ZEN-RGBW · by Prime Zen

ZEN-RGBW 4-Channel LED Strip Controller in Ahmedabad

The ZEN-RGBW is a 4-channel WiFi + RF controller for RGBW LED strips (Red + Green + Blue + White). Each channel delivers 3A at DC 12-24V, total 12A — drives up to 144W of strip at 12V or 288W at 24V. Full colour and brightness control from the Prime Zen app, voice assistants, or RF wireless switches. Compact enough to mount inside the LED-strip channel itself.

  • Output Channels4 (RGBW)
  • Voltage InputDC 12V – 24V
  • Current per Channel3A
  • Total Channel Current12A
  • Max Power @ 12V144W total
  • Max Power @ 24V288W total
  • Dimming MethodPWM
  • CommunicationWiFi 2.4GHz + RF 433MHz
Enquire on WhatsApp
  • Authorised Prime Zen partner
  • Manufacturer warranty
  • Delivery across India

How it works

Where this controller fits.

Installs at: Inline with RGBW LED strip · Light panel · Switch box.
Pairs with: Prime Zen S1/S2/S3/S4 wireless switches · Prime Zen app · Alexa · Google Assistant · Any RGBW LED strip (12-24V DC).

  • Dual protocol — WiFi 2.4GHz for app + voice control, RF 433MHz for direct wireless-switch pairing
  • Pairs with up to 10 Prime Zen wireless switches per channel
  • Voice control via Alexa and Google Assistant
  • Smartphone app control (iOS & Android)
  • Compact form factor — fits inside switch boxes, sockets and light panels
  • Standby power under 0.5W (0.8W on the analog dimmer)
  • Operating temperature -20 °C to +55 °C
  • -110 dBm RF receive sensitivity for reliable long-range operation

Specifications

Full spec sheet.

Complete technical specifications for the Prime Zen ZEN-RGBW. Call +91 91062 00232 or email contact@brightideas.in for quotation and load-compatibility verification.

Model NumberZEN-RGBW
BrandPrime Zen — Light Controller
FamilyRGBW Strip Controller
CategoryLighting Controls → Light Controllers
Output Channels4 (RGBW)
Voltage InputDC 12V – 24V
Current per Channel3A
Total Channel Current12A
Max Power @ 12V144W total
Max Power @ 24V288W total
Dimming MethodPWM
CommunicationWiFi 2.4GHz + RF 433MHz
Operating Range80 m outdoors · 25 m indoors
RF Sensitivity-110 dBm
DimensionsL44 × W44 × H22 mm
IP RatingIP20
Switch PairingUp to 10 wireless switches per channel
Working Temperature-20 °C to +55 °C
InstallationInline with RGBW LED strip · Light panel · Switch box
Compatible WithPrime Zen S1/S2/S3/S4 wireless switches · Prime Zen app · Alexa · Google Assistant · Any RGBW LED strip (12-24V DC)
WarrantyAs per Prime Zen manufacturer terms

Specifications sourced from Prime Zen's official catalogue. Bright Ideas is an authorised Prime Zen channel partner.

FAQs

Common buyer questions.

Where does the ZEN-RGBW get installed?

The ZEN-RGBW installs at the load end — inside a Inline with RGBW LED strip · Light panel · Switch box. It receives commands wirelessly and switches/dims the connected light, fan, LED strip or appliance accordingly. The compact form factor lets it hide inside existing electrical boxes without changing the look of your wall plate.

Do I control the ZEN-RGBW with my phone or with a wall switch?

Both — and voice. The controller has WiFi 2.4GHz for the Prime Zen smartphone app and voice assistants (Alexa & Google Assistant), plus RF 433MHz to pair directly with up to 10 Prime Zen wireless switches per channel. Use whichever you prefer, or all three.

Do I need a Prime Zen wireless switch to use this controller?

Not necessarily — the controller works standalone via WiFi (app + voice). The wireless switches are optional but add a physical-button option without rewiring. Most customers buy at least one switch per controller to keep manual control available even when WiFi is down. View the wireless switch range →

Will the ZEN-RGBW work with my existing LED lights?

Depends on the load. ZEN-RGBW is compatible with Prime Zen S1/S2/S3/S4 wireless switches · Prime Zen app · Alexa · Google Assistant · Any RGBW LED strip (12-24V DC). Our team verifies compatibility with your specific LED brand and driver at quotation — share the existing fixture details when you enquire.

Can I see the ZEN-RGBW at the showroom before ordering?

Yes — visit our Ahmedabad showroom at 111, First Floor, The Grand Monarch, Ahmedabad 380015. Working demonstrations of the full Prime Zen ecosystem (controllers + wireless switches + touch panels) available Mon–Sat, 10:30 AM – 7:30 PM.
