Linear Wall Washers

Hybec · Outdoor Lighting

10 models, built for the weather.

IP65 linear LED wall washers for architectural facade grazing, perimeter wall lighting and outdoor wall art illumination.

IP65 10 SKUs Hybec catalogue by Hybec →

Where these get used

Applications & typical installations.

Most commonly used in the project types below — across homes, hotels, commercial spaces and landscape projects.

  • Facade vertical grazing
  • Outdoor perimeter wall lighting
  • Architectural feature illumination
  • Hotel lobby exteriors
  • Commercial signage backlighting

A quick buyer's guide

How to pick the right one.

The things to think about when choosing the right model for your project — from weatherproofing to beam angle to how it gets mounted.

  1. 01 IP65 minimum for fully exposed facade use
  2. 02 Asymmetric optics for floor- or top-mounted grazing
  3. 03 Beam angles 10° / 30° / 60° for graze, flood or wash
  4. 04 Colour temperature 3000K for warm tone, 4000K for crisp architectural

What's standard across the range

Built-in quality features.

  • IP65 sealed extruded aluminium body
  • Multiple beam-angle options per model
  • Bridgelux / Cree LEDs
  • Mains or low-voltage variants

In this range

All 10 models.

Tap any model for the full specifications — wattage, beam angle, brightness, dimensions, weatherproof rating and LED source. Colour temperature and colour accuracy confirmed at quotation.

FAQs

Common buyer questions.

Quick answers to the questions we hear most often about this range.

What does a linear wall washer do?

It produces an even vertical wash of light across a wall or facade from a linear fixture mounted close to the surface. The point is uniformity — a properly specified wall washer lights the full height of the surface without visible scallops or hot spots.

How far from the wall should a wall washer be mounted?

Usually 150–400mm out from the surface, depending on the wall height and the optic. Mounting too close produces a bright band at the top and darkness below; too far and the fixture reads as a separate object rather than washing the surface.

What is the difference between wall washing and wall grazing?

Washing places the fixture further from the wall for even, flat illumination that plays down texture. Grazing places it very close so light rakes across the surface and exaggerates texture — right for stone, brick and fluted concrete, wrong for smooth plaster.

What IP rating do outdoor wall washers need?

IP65 minimum, IP66 where the fixture sits at ground level and could be hit by splash-back or irrigation. Linear fixtures have long gasket runs, so gasket quality matters more here than on a compact fixture.
