Underwater Concealed Lights

Hybec · Outdoor Lighting

8 models, built for the weather.

IP68 underwater concealed lights for swimming pools, fountains and decorative water features — recessed installation only.

IP68 8 SKUs Hybec catalogue by Hybec →

Where these get used

Applications & typical installations.

Most commonly used in the project types below — across homes, hotels, commercial spaces and landscape projects.

  • Swimming pool walls and floors
  • Decorative water features
  • Fountain basin lighting
  • Spa and hot-tub illumination
  • Reflecting pool feature lighting

A quick buyer's guide

How to pick the right one.

The things to think about when choosing the right model for your project — from weatherproofing to beam angle to how it gets mounted.

  1. 01 IP68 minimum — full submersion rated
  2. 02 12V or 24V low-voltage for swimmer safety
  3. 03 Recessed (concealed) installation only — not for surface mounting
  4. 04 RGB / colour-change options for decorative water features

What's standard across the range

Built-in quality features.

  • IP68 fully sealed body
  • Low-voltage 12V or 24V DC operation
  • Marine-grade stainless or coated alloy housing
  • Tempered glass face plate

In this range

All 8 models.

Tap any model for the full specifications — wattage, beam angle, brightness, dimensions, weatherproof rating and LED source. Colour temperature and colour accuracy confirmed at quotation.

FAQs

Common buyer questions.

Quick answers to the questions we hear most often about this range.

When should I choose concealed rather than surface underwater lights?

Choose concealed where the pool is still being built and you want no visible fixture body — the light sits in a cast niche and finishes flush with the wall. Surface fixtures are the retrofit option for an existing pool.

What IP rating do concealed underwater fixtures need?

IP68, rated for continuous submersion at the depth they will sit. Confirm the rated depth as well as the IP number — IP68 is defined by the manufacturer against a stated depth, not a universal standard.

Can concealed underwater lights be serviced later?

Yes, but the niche has to be designed for it. Specify a fixture with a serviceable front assembly and leave a cable loop in the niche so the unit can be drawn out for lamp or gasket replacement without draining more than the top of the pool.

Do concealed fixtures need a transformer?

Yes. They run on 12V or 24V SELV, so a transformer sits outside the pool zone in a dry, ventilated position. Size it with headroom above the connected load and keep the cable run short to avoid voltage drop across the circuit.
