Recessed Foot / Step Lights

Hybec · Outdoor Lighting

33 models, built for the weather.

Recessed outdoor step lights and floor washers for stairs, pathways, in-ground walkover and recessed architectural wall washing.

IP54 & IP65 33 SKUs Hybec catalogue by Hybec →

Where these get used

Applications & typical installations.

Most commonly used in the project types below — across homes, hotels, commercial spaces and landscape projects.

  • Recessed staircase risers
  • In-ground walkover and driveways
  • Recessed wall washing on garden compounds
  • Pool deck flush installations
  • Architectural floor markers

A quick buyer's guide

How to pick the right one.

The things to think about when choosing the right model for your project — from weatherproofing to beam angle to how it gets mounted.

  1. 01 IP65 minimum for in-ground and step applications
  2. 02 Drive-over rated variants for vehicular paths
  3. 03 Trimless / flush finish for clean architectural lines
  4. 04 Symmetric down-light for steps; asymmetric for wall wash

What's standard across the range

Built-in quality features.

  • Recessed body with mounting collar
  • Tempered glass or polycarbonate face
  • Drive-over rated options on select models
  • Bridgelux / Cree LEDs, IP65 sealed driver

In this range

All 33 models.

Tap any model for the full specifications — wattage, beam angle, brightness, dimensions, weatherproof rating and LED source. Colour temperature and colour accuracy confirmed at quotation.

FAQs

Common buyer questions.

Quick answers to the questions we hear most often about this range.

What is the difference between recessed step lights and walkover lights?

Recessed step lights are set into the riser of a step or into a wall at low level and are not designed to be walked on. Walkover fixtures are set into the tread or paving and are rated for foot and sometimes vehicle load, so they carry both an IP and an IK rating.

What IP and IK ratings do walkover lights need?

IP67 as a minimum for anything set into paving, since water will pond over it. For load, IK08 or above for foot traffic and a stated vehicle load rating if a car will cross it. Check both — a high IP rating says nothing about impact strength.

How far apart should step lights be spaced?

On a staircase, one fixture every second or third riser is usually enough — the aim is to make the edge of each tread readable, not to light the whole flight. On a path, 1.5 to 3 metres apart depending on the beam spread.

Will recessed step lights cause glare?

They can if the source is visible from eye level. Choose fixtures with a recessed emitter and an internal louvre, and aim them downward across the tread rather than outward. A step light that dazzles is worse than no step light.
