Hybec 22W Anti-Glare Downlight

22W Anti-Glare Downlight (HLR-2363) Anti-Glare · Gun Black Reflector Hybec

Recessed Downlight · Anti-Glare Series

Model HLR-2363 · by Hybec

Hybec 22W Anti-Glare Downlight Dealer in Ahmedabad

A 22W anti-glare recessed downlight with a deep gun-black reflector that cuts direct glare to a minimum — for living rooms, retail and hospitality ceilings where the light should be felt, not seen. OSRAM LED, 110° beam.

  • Wattage22W
  • Beam Angle110°
  • LED SourceOSRAM
  • Colour Temp3K/4K/6K
  • Cut-OutØ125mm
  • BodyWhite + Gun Black

Choose a variant

Enquire on WhatsApp
  • Datasheet & IES on request
  • Manufacturer warranty
  • PAN-India dispatch

Technical specifications

Full spec sheet.

Everything you need to drop HLR-2363 into a BOQ. IES photometric files and the manufacturer datasheet are available on request for Dialux / Relux simulation.

Model Number HLR-2363
Series Anti-Glare — Recessed Downlight
Brand Hybec
Wattage 22W
LED Source OSRAM
Beam Angle 110°
Colour Temperature 3K/4K/6K
Body Colour White + Gun Black
Dimensions Ø135 × 55mm
Cut-Out Ø125mm
Control Options Single Colour · Colour Changing / RF · RF / Bluetooth App
Warranty As per manufacturer terms

Specifications subject to change per the manufacturer's current catalogue. Datasheets and IES photometric files available on request.

You may also like

More recessed downlights.

View all recessed downlights →

Specifier FAQs

Common questions.

What CCT options are available for Hybec 22W Anti-Glare Downlight?

Standard SKUs ship with 3K / 4K / 6K CCT-switch (warm / neutral / cool on a single fixture, switchable at install). CCT-Tunable variants span 2700K-6000K continuously on select Hybec series. RGB+CCT Bluetooth variants available on the Tunable range.

Is Hybec 22W Anti-Glare Downlight suitable for a shallow false ceiling?

Typical recessed depth is 50-80mm — see the dimensions row in the spec sheet above for cut-out and overall dimensions. Low-Profile Hybec variants (HLR-2371/2/3/4/5) suit shallow plenums under 45mm depth.

What dimming protocols are supported?

TRIAC dimmable as standard across most Hybec recessed SKUs; 0-10V and DALI variants available on quotation. CCT-Tunable, Single Colour and RGB + CCT Bluetooth variants are listed where applicable in the Driver & Control row. Confirm at order.

Are datasheets and IES files available for Hybec 22W Anti-Glare Downlight?

Yes — manufacturer datasheet and IES photometric file for any Hybec recessed SKU is available on request for Dialux / Relux / AGi32 simulation by the lighting consultant.

What is the warranty?

As per Hybec manufacturer terms — standard 2-year warranty on the LED and driver, with PAN-India replacement support via Bright Ideas.
